a. (TP-601D)
The machine has already been set in its
adjustment is necessary, proceed as shown
in the following drawing.
Accumulator Box.
required, depending on the actual
quality or thickness of the strap used. If
27 and turn the Screw Bolt 28 counterclockwise.
in the Accumulator Box, loosen the Nut
a-1 In case that there is an insufficient amount of strap
strap in the Accumulator Box, loosen the Nut
a-2 In case that there is an excessive amount of
27 and turn the Screw Bolt 28 clockwise.
However, some adjustment may be
-16-
(4) Amount of strap in Accumulator Box
