Fromm TP-601D1 - Page 52

1-6 TENSION GROUP T6-1-60003
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 T6-1-60111 Tension Arm Shaft 1
2 T6-1-60120 Tension Arm Spring 1
4 T6-1-60140 Tension Arm Spacer 2
6 T6-1-60160 Tension Arm Spring Hook L-Type 1
7 BRHK2516 Bearing, HK2516 2
8 ER15 Snap Ring, E-15 2
11 BRIR202517 Bearing, IR202517 2
21 SP0680 Spring Pin, 6x80 1
41 T6-1-61001 Tension Arm Ass'y 1 SEE PAGE 21
42 T6-1-62000 Tension Jaw Ass'y 1
T6-1-62000S Tension Jaw Ass'y (Stainless 1
Steel Model)
53 HN08 HN, M8 2
-20-
01/10/08
