The “Arc break watchdog” function (Arc) is explained in the “Special functions and
options” section.
FCO
Feeder control - Wire-feed unit cut-out (wire end sensor option)
Unit -
Setting range OFF/ON/noE
Factory setting OFF
OFF: The power source halts wire feed when the wire end sensor is triggered. "Err|
056“ appears on the display.
ON: The power sources halts wire feed after completion of the current weld seam
when the wire-end sensor is triggered. "Err|056" appears on the display.
Acknowledge Err | 056
Insert a new wirespool and feed the wire electrode into the hosepack
noE: The power source does not halt wire feed when the wire end sensor is
triggered. The wire end alarm is not displayed and is only transmitted to the
robot control via the field bus.
NOTE!
The "noE" setting only functions in conjunction with the field bus applications.
Robot interfaces ROB 4000/5000 do not support this function.
SEt
Setting - Country-specific setting (Standard/USA)... Std/US
Unit -
Setting range Std, US (Standard/USA)
Factory setting Standard version: Std (measurements: cm/mm)
USA version: US (measurements in inches)
S4t
Special 4-step - Gun trigger (option)
Switch between jobs using torch trigger
Unit -
Setting range 0, 1 (Off, On)
Factory setting 1
Gun
Gun (welding torch) - Changing between modes with the JobMaster torch (optional)
Unit -
Setting range 0, 1 (Off, On)
Factory setting 1
NOTE!
The “Gun Trigger” (S4t) and “Changing between modes with the JobMaster weld-
ing torch” (Gun) options are explained in more detail in the “GunTrigger” operat-
ing instructions.
155
EN
