No. Function
(2) Keylock switch (optional)
When the key is in the horizontal position, the following functions are dis-
abled:
- Selecting the welding process using the Process button(s) (22)
- Selecting the mode using the Mode button(s) (23)
- Selecting the filler metal using the Material button(s) (24)
- Opening the Setup menu using the Store button (27)
- Opening the job correction menu (see “Job mode”)
NOTE! The functions available on the control panel of system com-
ponents are restricted in the same way as those on the control panel
of the power source.
(3) Parameter selection button
for selecting the following parameters:
a-dimension
1)
Dependent on the set welding speed
Sheet thickness
1)
Sheet thickness in mm or in.
Welding current
1)
Welding current in A
Before the start of welding, the machine automatically displays a
standard value based on the programmed parameters. During weld-
ing, the actual value is displayed.
Wire feed speed
1)
Wire feed speed in m/min or ipm.
F1 indicator
indicates that the current-input PushPull drive is switched on
Wire-feed rate drive current-input indicator
indicates that the wire-feed rate drive current-input is switched on
If the indicators are lit up on the parameter selection button (3) and on the
adjusting dial (21), then the indicated/selected parameter can be altered using
the adjusting dial (21).
1)
The synergic function means that if one of these parameters is selec-
ted during MIG/MAG pulse synergic welding or MIG/MAG standard
synergic welding, then all other parameters including the welding
voltage parameter are automatically set as well.
(4) F1 indicator LED
lights up when the F1 indicator parameter is selected
(5) Wire-feed rate drive current-input indicator LED
lights up when the wire-feed rate drive current-input indicator parameter is
selected
(6) a-dimension LED
lights up when the a-dimension parameter is selected
(7) Left digital display
(8) Sheet thickness LED
lights up when the sheet thickness parameter is selected
(9) Welding current LED
lights up when the welding current parameter is selected
39
EN
