Fronius IG Plus
100 V
Input data
Output data
General data
Safety equipment
MPP voltage range 230 - 500 V DC
Max. input voltage
(at 1000 W/m² / -10 °C in an open circuit)
600 V DC
Max. input current 37.1 A DC
Nominal output power (P
nom
)8 kW
Max output power 8 kW
Nominal AC output voltage 1 ~ NPE 230 V
2 ~ NPE 400 / 230 V
Grid voltage tolerance +10 / -15 %
1)
Nominal output current single-phase
two-phase
34.8 A AC
17.4 A AC
Nominal frequency 50 - 60 Hz
1)
Harmonic distortion < 3 %
Power factor (cos phi) 1
0.85 - 1 ind./cap.
3)
Max. permitted grid impedance Zmax
at PCC
2)
single-phase
two-phase
131 milliohms
262 milliohms
Maximum efficiency 95,7 %
Euro. efficiency 95,2 %
Night consumption Single-phase 0.36 W
two-phase 0.50 W
Cooling Controlled forced-air ventila-
tion
Degree of protection IP 54
in Australia, IP 44
Dimensions h x w x d 968 x 434 x 250 mm
Weight 36.9 kg
Permissible ambient temperature
(with 95% rel. humidity)
- 20 °C - +55 ?
EMC emissions class B
Over-voltage category (OVC) AC 3 / DC 2
DC insulation measurement Warning / Shutdown
4)
at R
ISO
< 500 kilohms
DC over-voltage protection integrated
Protection against reverse polarity integrated
Manifestation of DC overload Operating point shift
