Fronius IG Plus 100 V-1 User Manual

157
g
Fronius IG Plus
150 V
Input data
Output data
General data
Safety equipment
Explanation of
footnotes
1) The values provided are standard values. The inverter can be customized to the
respective country according to the requirements.
2) PCC = interface to the public grid
3) Depending on the country setup or device-specific settings
(ind. = inductive; cap. = capacitive)
4) Depending on the country setup
MPP voltage range 230 - 500 V DC
Max. input voltage
(at 1000 W/m² / -10 °C in an open circuit)
600 V DC
Max. input current 55.6 A DC
Nominal output power (P
nom
)12 kW
Max output power 12 kW
Nominal AC output voltage 3 ~ NPE 400 / 230 V
Grid voltage tolerance +10 / -15 %
1)
Nominal output current (three-phase) 17.4 A AC
Nominal frequency 50 - 60 Hz
1)
Harmonic distortion < 3,0 %
Power factor (cos phi) 1
0.85 - 1 ind./cap.
3)
Max. permitted grid impedance Zmax at PCC
2)
None
Maximum efficiency 95,9 %
Euro. efficiency 95,4 %
Night consumption 1.72 W
Cooling Controlled forced-air ventila-
tion
Degree of protection IP 54
in Australia, IP 44
Dimensions h x w x d 1263 x 434 x 250 mm
Weight 49.2 kg
Permissible ambient temperature
(with 95% rel. humidity)
- 20 °C - +55 ?
EMC emissions class B
Over-voltage category (OVC) AC 3 / DC 2
DC insulation measurement Warning / Shutdown
4)
at R
ISO
< 500 kilohms
DC over-voltage protection integrated
Protection against reverse polarity integrated
Manifestation of DC overload Operating point shift
