Fronius RI FB PRO/i - Page 39

Address
Signal
Activity/ Data type
Range
Factor
Process
Relative
Absolu-
te
Standard Economy
WORD
BYTE BIT
BIT
1
2
0 16
Command value out of
range
High
ü ü
1 17 Correction out of range High
2 18 —
3 19 Limitsignal High
4 20 —
5 21 —
6 22 Main supply status Low
7 23 —
3
0 24 Sensor status 1 High
See table Assign-
ment of Sensor Sta-
tuses 1–4 on page
42
1 25 Sensor status 2 High
2 26 Sensor status 3 High
3 27 Sensor status 4 High
4 28 —
5 29 —
6 30 —
7 31 —
2
4
0 32 —
ü ü
1 33 —
2 34 —
3 35 Safety status Bit 0 High See table Value ran-
ge Safety status on
page 43
4 36 Safety status Bit 1 High
5 37 —
6 38 Notification High
7 39 System not ready High
5
0 40 —
1 41 —
2 42 —
3 43 —
4 44 —
5 45 —
6 46 Active process line Bit 0 High See table Value ran-
ge of Active pro-
cess line Bit on page
43
7 47 Active process line Bit 1 High
