(2) Cleaning opening with internal parting-agent injection nozzle
for cleaning the gas nozzle and the inside of the welding torch
for coating the gas nozzle and welding torch interior with parting agent
(3) Dipping bowl with spill tray
(4) Standard I/O connection socket (X1)
(5) Mains cable with strain relief device (mains cable not provided with Robacta
TC 2000 Twin US)
(6) Spatter tray for welding residues (in optional installation stand)
(7) Recesses for the wire cutter holder
for attaching the wire cutter holder to the cleaning device
(8) Drain hose
for emptying the dipping bowl
(9) Parting agent nebuliser connection
for connecting to the "Robacta Reamer" parting agent container, for spraying the
compressed air/parting agent mixture into the cleaning opening
(10) Wire cutter connection socket
for electrically controlling the wire cutter
(11) Compressed air connection
for supplying the cleaning device with compressed air
NOTE! If the dipping bowl is not in use, ensure that there are no parting agent
residues left in the bottom.
NOTE! Ensure that there is always sufficient parting agent in the dipping
bowl when in use (i.e., ensure that the fill level indicator never lights up).
