6
Fronius Check-
box 500V techni-
cal data
Fronius Check-
box 500V status
LED
When the status LED lights up green, an electrical connection has been
established between the inverter and the battery.
Environmental conditions
Degree of protection IP65
Permissible ambient temperature -25 °C - +60 °C
Maximum altitude 2000 m
Permitted humidity 0 - 100% (non-condensing)
Electrical specifications
Maximum input voltage
Inverter side
Battery side
Udc max in_INV
Udc max out_BAT
1000 V
500 V
Maximum current Idc max in / max out 16 A
Self-consumption @ 450 V 1.9 W
Dimensions and weight
Dimensions h x w x d (without packaging) 26 x 19 x 7.5 cm
Weight (without packaging) 1.4 kg
Dimensions h x w x d (with packaging) 36 x 30 x 13 cm
Weight (with packaging) 1.9 kg
Standards and directives
Applicable standards and directives LVD (2014/53/EU), IEC 62109-1
