35 SERIES GAS FRYERS
CHAPTER 2: INSTALLATION INSTRUCTIONS
2-3
1. Adequate means must be provided to limit the movement of fryers without depending upon the gas line
connections. If a flexible gas hose is used, a restraining cable must be connected at all times when the
fryer is in use. The restraining cable and installation instructions are packed with the flexible hose in the
accessories box that was shipped with your unit.
2. Single unit fryers must be stabilized by installing restraining chains on fryers equipped with casters or
anchor straps on fryers equipped with legs. Follow the instructions shipped with the casters/legs to
properly install the chains or straps.
3. Level fryers equipped with legs by extending the adjustable portion of the leg out approximately 1 inch,
and then further adjust the legs, ensuring the fryer is level and at the proper height in the exhaust hood.
Frymaster recommends that the minimum distance from the flue outlet to the bottom edge of the filter be
24 in. (600 mm) when the appliance consumes more than 120,000 BTU per hour.
For fryers equipped with casters, there are no built-in leveling devices. The floor where the fryer is to
be installed must be level.
4. Test the fryer electrical system:
• For fryers equipped with thermostat controls, verify that the power and heat lights are lit.
5. Refer to the data plate on the inside of the fryer door to determine if the fryer burner is configured for
the proper type of gas before connecting the fryer quick-disconnect device or piping from the gas sup-
ply line.
6. Verify that the minimum and maximum gas supply pressures for the type of gas to be used are in accor-
dance with the following tables.
7. For fryers equipped with a Filter Magic II system
and/or basket lifts, plug the electrical cord(s) into a power receptacle behind the fryer.
Non-CE Standard in Incoming Gas
Pressure
Gas Minimum Maximum
Natural
6” WC
1.49 kPa
14.93 mbar
14” WC
3.48 kPa
34.84 mbar
LP
11” WC
2.74 kPa
27.37 mbar
14” WC
3.48 k Pa
34.84 mbar
CE Standard in Incoming
Gas Pressure
Gas Minimum Maximum
G20 20 mbar 20 mbar
G25 20 mbar 25 mbar
G31 37 mbar 50 mbar
