Scopes & Audio Meters Menu
Main Menu Scopes & Audio Meters
Function Scopes & Audio Meters Prole 1
Scopes & Audio Meters Window 1 Luminance
Video Window 2 Vector
Audio Waveform Position Bottom Right
Marker Scopes Stack Horizontal
Alarm Waveform Scale IRE Level
OSD Audio Display Mode Pairs
GPI Alignment Level -18 dBFS
Color Management Permitted Max Level -9 dBFS
System Audio Display Channels 1-16
System Status Ballistics True Peak
Support Peak Hold Time 2
Scopes & Audio Meters Prole 1, 2, 3
The Scopes & Audio Meters menu allows you to setup three Scopes & Audio Meters Proles, each capable of storing all of
the congurable settings found on the Scopes & Audio Meters Menu. To congure a Prole simply select the Prole number,
1 through 3, from the top of the Scopes & Audio Meters menu page. Once you have selected the desired prole number any
settings you change will become associated with that prole number. Changing from one prole to another from the Scopes
and Audio Meters menu will automatically recall your last settings for that prole. Once you have congured your Scopes
& Audio Meters proles you can assign a specic function key to a particular prole, which allows you to instantly switch
between different types of Scope and/or Audio Meters modes without having to go back into the onscreen menu.
Window 1 & Window 2
Two scope windows can be displayed simultaneously so you can view any two of the following modes at the same time:
Luminance (Standard Waveform), Vector Scope, Hue Vector*, RGB Parade, GBR Parade, RGB Overlay, YCbCr, YCbCr
Overlay, Column (YRGB Peak), Histogram, Color Histogram, RGB Histogram, Audio Loudness, Audio Phase, and Vertical
Audio Level Meter. Please note that displaying two Scope Windows at the same time will cause the Scopes to update more
slowly than displaying just one Scope Window. To display just one scope Window select OFF in the secondary window
selection. An additional audio level meter mode called horizontal audio level meter is also selectable. This mode displays
meters horizontally across the top of the screen, but cannot be used in conjunction with any other Scope modes. Waveform
Intensity and Gain can be adjusted by turning the H POS and V POS rotary knobs. Default Scope Intensity as
of rmware version 9.42 is 75% of the maximum level. Hue Vector Intensity, Gain, Reference Vector Angle, and
Percentage of Reference Vector can be adjusted with the H POS, V POS, Ref POS, and F Stop rotary knobs. Audio
Loudness metering can be paused and reset using the H POS rotary knob.
*Hue Vectors graticule designed by Alexis Van Hurkman and used under Creative Commons License..
Waveform Position
Use the Waveform Position toggle to select in what area of the screen you would like your Scopes to be displayed.
Scopes Stack
Use this option to select whether the Scope Windows are stacked vertically or positioned horizontally next to each other
when utilizing two Scope Windows.
Waveform Scale
This option allows you to choose what type of scale is used on the Waveform Monitor. You may select from V Level (for a
voltage based scale), IRE Level (for an IRE based scale 0-100), or Digital Level (for a 8 bit digital level based scaled, 0-255).
NOTE: The Scope & Audio
Meters Menu only sets your
Waveform, Vector, & Audio Level
Meter display preferences. To
toggle the onscreen display
of your congured Scopes &
VU Meters proles assign the
Scopes & VU Meters proles to
specic keys. See the Function
Menu section of this manual for
more details.
