OSD Menu
Main Menu OSD
Function Status Display 5 s
Scopes & Audio Meters Menu Position Top Right
Video Status Position Top Left
Audio Rotary Position Bottom
Marker Source ID Off
Alarm Source ID Position Bottom
OSD Source ID Character CAM1
GPI Time Code Off
Color Management Time Code Size Small
System Time Code Position Top
System Status Time Code Bg Translucent Black
Support
Status Display
Toggles settings for pop up window indicating resolution and frame rate of source when input button is pressed or a new
signal type is routed to monitor. Setting this option to Off turns the Status Display function completely off, setting to ‘5 s’
enables a 5 second onscreen status display when the input button is pressed or source format is changed, and setting to
On leaves the Status Display onscreen permanently.
Menu Position
Changes position of onscreen menu between three choices: Center, Top Left, or Top Right.
Status Position
Changes position of onscreen status display window. Select from Top Left, Top Right, Bottom Left, Bottom Right, or Center.
Rotary Position
Changes position of onscreen window indicating status of any rotary knob (Volume, Contrast, etc.) during adjustment.
Select from Top, Center, or Bottom.
Source ID
Allows you toggle source ID function on/off. The Source ID function can be used to set a manual onscreen label of up to 5
characters. This is often used to allow for the labeling of a monitor as PGM, PVM, CAM, etc. without using placards or tape.
Source ID Position
Changes position of onscreen Source ID function.
Source ID Character
Allows you to customize text for Source ID label using ENTER, UP, and DOWN buttons.
Time Code
Allows you to select whether to display Time Code on screen pulled from an HD/SD-SDI signal. Select between Off, LTC,
VITC 1, or VITC 2. Please note that Time Code cannot be displayed at the same time as Scopes, Markers, or other onscreen
ancillary functions.
Time Code Size, Position, & Bg
Allows you to toggle between Large or Small Timecode Display, change the onscreen position of timecode, and select
translucent black or solid blue background.
