Alarm Menu
Main Menu Alarm
Function Alarm Off
Scopes & Audio Meters Visual Alarm Off
Video Remote Alarm Monitoring Off
Audio IRE Trigger Level 100 IRE
Marker Audio Trigger Time 3s
Alarm Audio Phase Indicator Off
OSD UMD Display UMD
GPI UMD Color White
Color Management UMD Position Top
System Audio Meter Vertical
System Status Select Alarm Area
Support
The monitor’s built in Alarm system allows for simplied QC monitoring of signals with minimal overlap of active video.
The alarm monitoring system allows you to specify alarm parameters that will trigger onscreen and/or remotely monitored
warnings when a specied condition is met. This feature provides an unobtrusive QC viewing mode compared to having
onscreen scopes active at all times. Please note the alarm monitoring capabilities are limited by the processing power of
the monitor. The signal will be sampled at a variable rate depending on other processing loads placed on the monitor. With
minimal additional processing demands the fastest sample rate is approximately every 2 to 3 frames. It is therefore possible
that an alarm event occurring for only 1 or 2 frames may be missed by the alarm monitoring system. The alarm monitoring
system is a useful tool for quick analysis of content to make sure no serious errors exist, but it should not be used as
substitute for standalone legalizers and signal level monitoring systems in ultra-critical level monitoring applications.
Alarm
Selects the type of alarm events that will be monitored. This selection only affects onscreen (visual) alarms and does not
change what alarm events can be monitored through the remote control alarm monitoring software.
Safety Alarm: Will trigger an alarm if a loss of signal is detected, a full black eld is detected, a full blue eld is
detected, and/or embedded audio goes mute for the amount of time specied in the Audio Trigger Time setting.
The audio mute alarm will only trigger if audio is being embedded into the signal and is mute for the specied
amount of time, there will be no audio mute warning if audio is not being embedded into the SDI signal.
Safety Video Alarm: Same as Safety Alarm minus audio alarms.
IRE Alarm: Will trigger an alarm if the IRE level specied in the IRE Trigger Level setting is exceeded.
RGB Alarm: Will trigger an alarm if any RGB Levels exceed 100 IRE.
IRE & RGB Alarm: Combines IRE and RGB Alarms and will trigger an alarm if either or both exceed their set
parameters.
All Alarms: Will trigger an alarm if any alarm condition is met (Loss of Signal, Black Field, Blue Field, Audio Mute,
IRE threshold exceeded, RGB levels over 100 IRE).
Visual Alarm
When set to ON a small box will appear on the monitor’s screen whenever the
alarm condition set in the Alarm menu selection explained above is triggered.
NOTE: Onscreen Alarms are
processing power intensive.
When active the monitor may
respond more slowly to user
input via buttons/remote control
if a large number of successive
alarm events are occurring.
Switching to an unused input with
no video will allow the monitor
to respond quickly to user input
should the operator simply want
to turn Alarm monitoring off in
scenarios where monitor menu
response is slowed by such
successive alarm events.
Alarm
IRE
