Audio Menu
Main Menu Audio
Function SDI 1 Audio Digital CH1&2
Scopes & Audio Meters SDI 2 Audio Digital CH1&2
Video DVI-D Audio Digital CH1&2
Audio DVI-A Audio Analog
Marker Component Audio Analog
Alarm Composite Audio Analog
OSD Audio Sync Signal Clock
GPI Audio Lockout Off
Color Management
System
System Status
Support
SDI 1 Audio
Select which audio source is active (audible) when SDI 1 is the selected video input. You may select any single channel or
stereo pair of embedded audio (i.e. Digital Channel 1, 1&2, 3&4, etc.), Analog Audio (from minijack input), or No Sound. The
active stereo pair selected here will be the stereo pair shown when the Audio Phase Meter is activated on the SDI 1 Input.
SDI 2 Audio
Select which audio source is active (audible) when SDI 2 is the selected video input. You may select any single channel or
stereo pair of embedded audio (i.e. Digital Channel 1, 1&2, 3&4, etc.), Analog Audio (from minijack input), or No Sound. The
active stereo pair selected here will be the stereo pair shown when the Audio Phase Meter is activated on the SDI 2 Input.
DVI-D Audio
Select between Analog Audio input (via minijack connector) or No Sound when DVI-Digital is the selected video input. On
monitors shipped AFTER October 27th, 2014 you can also use the Channel 1 & 2 selection listed here for stereo HDMI
audio support when using a HDMI or Display Port to DVI cable.
DVI-A Audio
Select between Analog Audio input (via minijack connector) or No Sound when DVI-Analog is the selected video input.
Component Audio
Select between Analog Audio input (via minijack connector) or No Sound when Component Video is the selected video
input.
CVBS Audio
Select between Analog Audio input (via minijack connector) or No Sound when Composite Video is the selected video input.
Audio Sync
Choose between Signal Clock or Internal Clock for Audio Sync. Some embedded audio sources may have a poor quality
signal clock that may lead to audio distortion. Switching to Internal Clock can help to eliminate or minimize such distortion.
Audio Lockout
When set to On, this feature will lock the Volume Knob, which retains the last used audio setting used. With Audio Lockout
On, no adjustments to volume will be possible.
