Menu Navigation & System Status
Main Menu
Pressing the MENU button on the monitor’s keypad will call up the On Screen Menu, as shown below:
Main Menu Function
Function F1 Scopes & Audio Meters 1
Scopes & Audio Meters F2 Scopes & Audio Meters 2
Video F3 Scopes & Audio Meters 3
Audio F4 Marker 1
Marker F5 Measurement (10Bit)
Alarm Function Display On
OSD
GPI
Color Management
System
System Status
Support
Navigating the Main Menu
To navigate the Main Menu simply use the UP and DOWN keys to highlight a category and press the ENTER button to
select the highlighted sub menu. Navigate the sub menu in the same way by using the UP and DOWN keys to highlight a
particular function and press ENTER to toggle between that function’s settings. To exit the menu or back out of a sub menu
simply press the MENU button.
System Status
The System Status menu does not contain any congurable settings but does provide important information regarding your
monitor’s serial number, rmware version, & current conguration.
Main Menu System Status
Function Input SDI 1
Scopes & Audio Meters Video Format 1080p 60hz
Video PAP Input SDI 2
Audio Video Format No Signal
Marker Volume 16
Alarm Contrast 0
OSD Brightness 0
GPI Chroma 0
Color Management Hue 0
System Model CM250-3G
System Status S/N M250A00000
Support System Version 1.1.03-2144
Pressing an input button will temporarily call up a secondary system status summary window that will indicate incoming
signal resolution and frame rate, active color space selected on Color Management menu, gamma response selected on
Video Menu, & color matching function selected on Color Management Menu*.
*Color Matching Function toggle only works on OLED units, all other units currently use CIE 1931 CMF only.
