Section 3 Mechanical Installation & Lightning Protection

15 FT722 & FT742 (RS485) – FF & PM Sensors – User Manual

Figure 3: Flat Front Wind Sensor

The sensor measures the wind direction relative to the mounting flat and bar. When the wind sensor is correctly

aligned the wind direction measurements will be as shown in Figure 4.
