Method 2) Calculating
1) Value (a) is returned from the get data (aD!) command in the health status field. Find the value
(b) in the Health Status Table that is closest to but less than (a). Value (b) indicates the first health
status indicator.
2) Subtract (b) from (a): a-b= c
3) Find the value (d) in the Health Status/Error Table that is closest to but less than (c). Value (d)
indicates the second health status indicator.
4) Subtract (d) from (c): c-d = (e)
5) Find the value (f) in the Health Status/Error Table that is closest to but less than (e). Value (f)
indicates the third health status indicator.
6) Continue in this fashion until the difference of the two values = 0
Example: 0D0! +5.23+0+23.5+7-1.3+20+30+12.5+263
1) Value (a) = 263. Value (b) = 256 Battery out of range
2) 263-256 = 7. Health status value closest to 7 is 4= Needs date and time set
3) 7 – 4 = 3 Health status value closest to 3 is 2= the Bubbler has rebooted
4) 3-2 = 1 Health status Value closest to 1 is 1= data logger and Bubbler are out of
Synchronization
5) 1-1 = 0 No further indicators
STATUS CODES
VALUE
MEANING
0
Bubbler operating normally
1
Data logger & Bubbler out of sync
2
Has rebooted
4
Needs date & time set
256
Battery out of range
512
Temperature out of range
1024
Compressor fault
2048
Line blocked
4096
Line pressure high
8192
Tank leak
16384
System Error
BIT
INDICATES
BIT
INDICATES
0
DL & Bubbler out of sync
10
Compressor fault
1
Has rebooted
11
Line blocked
2
Needs date & time set
12
Line pressure high
3-7
Not used (always 0)
13
Tank leak
8
Battery out of range
14
System Error
9
Temperature out of range
15
Voltage low
