FTS MAXI-COOL - Removal of Panels

Maintenance
Maxi-Cool
30 Rev 007, 04/12
© SP Scientific 2012
Side Panel
Side Panel
Removal of Panels
Ensure the power is turned off, move the breaker on the back of the unit to 1.
the OFF position and push in the EMO on the front panel.
Loosen the screws along the back edge of the side panels. 2.
Pull off panels and place them out of the way. 3.
Front Panel
