SeaSTAR 3610 USER MANUAL
• In VBS mode, the RTCM data will appear on the output ports A and/or B. The ports
will need to be set up to match the requirements of your GPS receiver RTCM
IN/NMEA out port, use the Port cfg menu item to set these (see page 16).
• For the VBS operation, the 3610 DGNSS receiver needs to be supplied with a
position for the area of operation. Insert the position via the Set pos/Ch menu
(see page 15).
• In VBS mode, the VBS output must be enabled.
3610 receiver
GPS receiver
DGNSS antenna
DC power supply
A and/or B
PWR
ANT
Figure 3. Operating in VBS mode
Issue 2.0 02/10
8
