SeaSTAR 3610 USER MANUAL
TECHNICAL SPECIFICATIONS
Radio frequencies
Receiver frequency band: ................................................................ 1525 – 1559 MHz
Channel bandwidth: ............................................................................................. 5 kHz
Physical dimensions
Width: ........................................................................................................... 109.5 mm
Height: .............................................................................................................. 65 mm
Depth: ............................................................................................................. 253 mm
Weight: ................................................................................................................. 0.8 kg
Colour housing: .................................................................................... Clear anodizing
Power
Voltage: .......................................................................................................... 9-24 VDC
Power consumption: .......................................................................................... < 12 W
Environmental specifications
Enclosure material: ....................................................................................... Aluminium
Enclosure protection: ............................................................................................ IP-22
Operating temperature range: .................................................................... -5 to +55 ºC
Recommended operating temperature range: ....................................... +20 to +25 ºC
Operating humidity: ............................................................. Max.95% non-condensing
Storage temperature range: ..................................................................... -20 to +65 ºC
Storage humidity: ................................................................................... Less than 55%
Connectors
RF input to receiver: ................................................................................... TNC female
Power connector: ................................................................ Hirose LF07WBR-6P male
Ethernet connector: ............................................................................................... RJ45
Serial connectors: ............................................................................ 9-pin DSub female
Cables
Coax cables: ....................................... 1/2" CELLFLEX
®
Superflexible (SCF12-50JFN)
Serial cables: .............................................. RS-232 ( RS-422) LIYCY 3 x 2x 0.14 mm
2
Power cable: .................................................................................. SKUB 2 x 0.75 mm
2
Compass safe distance
Steering magnetic compass: ................................................................................ 0.2 m
Standard compass: .............................................................................................. 0.4 m
Data input and output
Two serial ports: ................................................................................................ A and B
Electrical interfaces: ...................................................................... RS-232 and RS-422
Baud rates: .......................................................................................... 2400 – 115 200
Serial data format:............................................................................. .................. N, 8, 1
IP interface
Protocol support:........................................................................ .............. ..NTRIP, FTP
