SeaSTAR 3610 USER MANUAL
System components
A standard delivery of the 3610 DGNSS receiver with a spotbeam antenna consists of
the following parts:
1. 3610 DGNSS receiver unit
2. Coax cable RG-58 – N-male to N-female, 1 m
3. Coax cable RG-58 – TNC-male to N-female, 1 m
4. 2 x RS-232 serial cables LIYCY 3 x 2 x 0.14 mm
2
, 9-pin DSub male to 9-pin
DSub female, 2 m length
5. Power supply 85 V AC...265 V AC / 24 VDC / 0.75 A
6. AC power lead set, 2P, SKX/H03VVH-F, 2 × 0.75 mm
2
, 2 m length
7. DC power lead, SKUB 2 x 0.75 mm
2
red (+)/black (-) with connector of type
Hirose LF07WBP-6S female, 1.5 m length
8. Mounting brackets with screws
9. CD or USB stick with this manual
10. DGNSS spotbeam antenna with brackets
A standard delivery of the 3610 DGNSS receiver for Inmarsat consists of the following
parts:
1. 3610 DGNSS receiver unit
2. 2 x Coax cable RG-223 – N-male to TNC-male, 1 m
3. Coax cable RG-223 – N-male to TNC-female, 1 m
4. 2 x RS-232 serial cables LIYCY 3 x 2x 0.14 mm
2
, 9-pin DSub male to 9-pin
DSub female, 2 m length
5. Power supply 85 V AC...265 V AC / 24 VDC / 0.75 A
6. AC power lead set, 2P, SKX/H03VVH-F, 2 × 0.75 mm
2
, 2 m length
7. DC power lead, SKUB 2 x 0.75 mm
2
red( +)/black (-) with connector of type
Hirose LF07WBP-6S female, 1.5 m length
8. Mounting brackets with screws
9. CD or USB stick with this manual
Issue 2.0 02/10
