Serial lines
The panel connectors for Com A and Com B are DB9 female. Pin layout is described
below:
Pin no. Signal
1 RS-422 TX+
2 RS-232 TXD
3 RS-232 RXD
4 Not in use
5 GND
6 RS-422 TX-
7 Not in use
8 RS-422 RX+
9 RS-422 RX-
Table 2 Serial line pin layout
A special serial cable is supplied with the DGNSS receiver. The cable is terminated
as described below.
DB9 male
Pin number
2 metre cable
DB9 female
Pin number
2 -------------------- 2
3 -------------------- 3
5 -------------------- 4
Table 3 RS-232 data cable layout
Note! Do not use standard RS-232 cables
