5-56
P01 Motor 1 (No. of poles)
P01 specifies the number of poles of the motor. Enter the value given on the nameplate of the
motor. This setting is used to display the motor speed on the LED monitor (refer to E43). The
following expression is used for the conversion.
120
Motor speed (r/min) =
No. of poles
x Frequency (Hz)
P02 Motor 1 (Rated capacity)
P02 specifies the rated capacity of the motor. Enter the rated value given on the nameplate of
the motor.
Data for P02 Unit Remarks
kW When P99 = 0, 3 or 4
0.01 to 30.00
HP When P99 = 1
P03 Motor 1 (Rated current)
P03 specifies the rated current of the motor. Enter the rated value given on the nameplate of
the motor.
P04 Motor 1 (Auto-tuning)
The inverter automatically detects the motor parameters and saves them in its internal
memory. Basically, it is not necessary to perform tuning when using a Fuji standard motor with
a standard connection with the inverter.
In any of the following cases, perform auto-tuning since the motor parameters are different
from those of Fuji standard motors so as not to obtain the best performance under each of
these controls--auto torque boost, torque calculation monitoring, auto energy saving
operation, torque limiter, automatic deceleration (anti-regenerative control), auto search for
idling motor speed, slip compensation, torque vector, droop control, or overload stop.
• The motor to be driven is made by other manufacturer or is a non-standard motor.
• Cabling between the motor and the inverter is long.
• A reactor is inserted between the motor and the inverter.
For details of auto-tuning, refer to Section 4.1.3 "Preparation before running the motor
for a test -- Setting function code data."
P05 Motor 1 (Online tuning)
The primary and secondary % resistances (%R1) and (%R2) will change as the motor
temperature rises. P05 allows you to tune this change when the inverter is in operation
(online)
P06, P07
P08, P12
Motor 1 (No-load current, %R1, %X and Motor 1, Rated slip frequency)
P06 through P08 and P12 specify no-load current, %R1, %X, and rated slip frequency,
respectively. Obtain the appropriate values from the test report of the motor or by calling the
manufacturer of the motor.
Performing auto-tuning automatically sets these parameters.
No-load current (P06): Enter the value obtained from the motor manufacturer.
%R1 (P07): Enter the value calculated by the following expression.
(%)=1%R 100×
)I×3(/V
1RCable+1R
