10.3.3 Leakage current from EMC-filter built-in type inverters or inverters with an external
EMC-complaint filter (optional)
Table 10.1 Leakage Current from EMC Filter Built-in Type Inverter
Leakage current (mA) *
1)
Input power
Inverter type
Normal Worst *2
)
FRNF12E1E-2U
FRNF25E1E-2U
FRNF50E1E-2U
FRN001E1E-2U
7.5 7.5
FRN002E1E-2U
FRN003E1E-2U
FRN005E1E-2U
13.0 20.0
FRN007E1E-2U
FRN010E1E-2U
FRN015E1E-2U
Three-phase
230 V
FRN020E1E-2U
21.0 21.0
FRNF50E1E-4U
FRN001E1E-4U
5.4 33.0
FRN002E1E-4U
FRN003E1E-4U
FRN005E1E-4U
3.8 25.0
FRN007E1E-4U
FRN010E1E-4U
3.8 11.7
FRN015E1E-4U
Three-phase
460 V
FRN020E1E-4U
6.8 22.3
FRNF12E1E-7U
FRNF25E1E-7U
FRNF50E1E-7U
FRN001E1E-7U
8.3 8.3
FRN002E1E-7U
Single-phase
230 V
FRN003E1E-7U
4.1 8.2
*1) The values are calculated assuming the power supplies of three-phase 240 V (50 Hz), three-
phase 400 V (50 Hz), and single-phase 230 V (50 Hz).
*2) The worst condition includes a phase loss in the supply line.
