3-26
Basic key operation
To view the alarm information, set function code E52 to "2" (Full-menu mode) beforehand.
(1) Turn the inverter ON. It automatically enters Running mode. In that mode, press the
key to
switch to Programming mode. The function selection menu appears.
(2) Use the
and keys to display "Alarm Information" (
CN
).
(3) Press the
key to proceed to a list of alarm codes (e.g.
N
).
In the list of alarm codes, the alarm information for the last 4 alarms is saved as an alarm history.
(4) Each time the
or key is pressed, the last 4 alarms are displayed in order from the most
recent one as
,
,
and
.
(5) While the alarm code is displayed, press the
key to have the corresponding alarm item
number (e.g.
A
) and data (e.g. Output frequency) displayed alternately in intervals of
approximately 1 second. You can also have the item number (e.g.
A
) and data (e.g. Output
current) for any other item displayed using the
and keys.
(6) Press the
key to return to a list of alarm codes. Press the key again to return to the menu.
Table 3.21 Alarm Information Displayed
LED monitor
shows:
(item No.)
Item displayed Description
A
Output frequency Output frequency
A
Output current Output current
A
Output voltage Output voltage
A
Calculated
torque
Calculated motor output torque
A
Reference
frequency
Frequency specified by frequency command
A
Rotational
direction
This shows the rotational direction being output.
H
: forward,
T
: reverse, : stop
A
Running status
This shows the running status in hexadecimal. Refer to
" Displaying running status
" in Section 3.4.4.
A
Cumulative run
time
Shows the content of the cumulative power-ON time counter of the
inverter.
Unit: thousands of hours.
(Display range: 0.001 to 9.999, 10.00 to 65.53)
When the total ON-time is less than 10000 hours (display: 0.001 to
9.999), data is shown in units of one hour (0.001). When the total
time is 10000 hours or more (display: 10.00 to 65.53), it is shown in
units of 10 hours (0.01). When the total time exceeds 65535 hours,
the counter will be reset to 0 and the count will start again.
A
No. of startups
Shows the content of the cumulative counter of times the inverter is
started up (i.e., the number of run commands issued).
1.000 indicates 1000 times. When any number from 0.001 to 9.999
is displayed, the counter increases by 0.001 per startup, and when
any number from 10.00 to 65.53 is counted, the counter increases
by 0.01 every 10 startups. When the counted number exceeds
65535, the counter will be reset to 0 and the count will start again.
A
DC link bus
voltage
Shows the DC link bus voltage of the inverter main circuit.
Unit: V (volts)
