Fax
4
4 Fax
198
+ Add (Sending Faxes to Multiple Recipients)
The Broadcast Send feature allows you to transmit the same document to multiple
recipients in a single operation. There is no need to repeat the same operation for each
recipient.
When the Additional G3 Port 2 (optional) is installed, you can use the extra lines to
make multiple transmissions simultaneously with Broadcast Send.
If you specify Broadcast Send, the machine prints a Broadcast/Multi-Poll Report after
the Broadcast Send operation finishes.
Note • For Fax and Internet Fax, the maximum number of recipients that you can specify at one
time is as follows:
Using the numeric keypad only: 200 locations; using address numbers only: 600 locations;
and using both the numeric keypad and address numbers: 600 locations.
For Server Fax, the maximum number of recipients that you can specify at one time is 50.
• The address numbers 0001 - 0070, or 0001 - 0060 correspond to the one touch buttons 1 -
70, or 1 - 60. For more information on the one touch buttons, refer to "Control Panel" (P.56).
• When using Broadcast Send, the Cover Page and Remote Folder features are not available
even if they are enabled on the control panel. If you want to use [Cover Page] and [Remote
Folder], set them when registering each recipient in an address number.
• You cannot specify [Confirmation Options].
Show Fax No./E-mail Address
If you select this check box, the recipient’s name will not be displayed in the recipient
field.
Enable Broadcast
To prevent missending a fax to multiple recipients, you can set whether to use
Broadcast Send prior to specifying multiple recipients. Select the [Enable Broadcast]
check box to specify multiple recipients.
[Enable Broadcast] is displayed only when [Broadcast Checkbox on 1st Tab] is set to [Enabled]. For
more information on the setting, refer to "5 Tools" > "Fax Service Settings" > "Fax Control" >
"Broadcast Checkbox on 1st Tab" in the Administrator Guide.
1 Select the first recipient.
2 Select [+ Add].
Note • Depending on the settings, a screen to re-enter the recipient may be displayed after
specifying the recipient and then selecting [+ Add] on the touch screen. In that case, re-enter
the recipient.
3 Select the next recipient.
4 Repeat steps 2 and 3.
5 Press the <Start> button.
6 Select [Yes] on the confirmation screen to start transmission.

Table of Contents

Other manuals for Fuji Xerox ApeosPort-IV C5570

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fuji Xerox ApeosPort-IV C5570 and is the answer not in the manual?

Fuji Xerox ApeosPort-IV C5570 Specifications

General IconGeneral
Print Resolution1200 x 2400 dpi
Scan Resolution600 x 600 dpi
FunctionsPrint, Copy, Scan, Fax
Duplex PrintingYes
Fax Transmission Speed33.6 kbps
Operating System CompatibilityWindows, Mac OS, Linux
Print Speed55 ppm (color and monochrome)
Monthly Duty Cycle300, 000 pages
ConnectivityEthernet, USB
Paper SizeA3, A4, A5, B4, B5
Memory2 GB
Hard Disk Drive160 GB
Copy Speed55 cpm (black/white and color)
