2 Product Overview
60
Product Overview
2
Large Size UI
The installation of the Large Size UI (optional) allows you to lay out where to locate the
touch screen.
The following describes the names and functions on the Large Size UI.
Note • As the Large Size UI does not support the one touch panels, you cannot specify recipients
with the one touch buttons.
No. Component Function
1 Touch screen Displays messages required for operation and buttons for various
features. You can directly touch the touch screen to instruct operations
and set features.
1 2 3 4
20
18
19
14
5
6
7
8
9
10
11
12
131617 15
To Next Page
