15 Problem Solving
572
Problem Solving
15
Paper Jams at the Tri-fold Output Tray [2d] and the Handle [2g]
1
Make sure that the machine has stopped, and
open the folder unit door of the Folder Unit
CD1.
2
Pull out the Tri-fold output tray [2d] (1), and
move the handle [2g] to the right (2). Remove
the jammed paper (3).
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
3
Return the handle [2g] (1), and push the Tri-
fold output tray [2d] in (2).
4
Close the folder unit door of the Folder Unit CD1.
Note • A message will be displayed and the machine will not operate if the folder unit door of the Folder
Unit CD1 is even slightly open.
To Next Page
