16 Appendix
594
Appendix
16
îš„ Side Tray (Optional)
îš„ HCF (Optional)
Paper Size Same as the Basic Specifications / Copy Function
Paper Weight Same as the Basic Specifications / Copy Function
Paper Capacity 100 sheets
Important • When using 80 gsm paper
Dimensions/Weight Width 274 x Depth 469 x Height 128 mm, 1 kg
Space Requirement (when
connected to the main
unit)
Width 988 x Depth 699 mm (Main Unit + HCF)
Important • When the Tray 5 (Bypass) is fully extended.
Paper Size
A4 , B5 , Letter
Paper Weight 56 - 216 gsm
Capacity 2000 sheets
Important • When using 80 gsm paper
Dimensions/Weight Width 389 x Depth 610 x Height 380 mm, 29 kg
Space Requirement (when
connected to the main
unit)
Width 989 x Depth 699 mm (Main Unit + HCF)
Important • When the Tray 5 (Bypass) is fully extended.
