Replacing Consumables
71
Maintenance
3
3
With grasping the orange lever, pull out the
staple cartridge.
Note • The staple cartridge is firmly inserted. A slight
force is required to pull the cartridge out of
the finisher.
• When the C3 Finisher Staple Unit 65 Sheets is
installed, pull down the orange lever, and pull
out the staple cartridge.
4
Pinch both sides of the empty staple case with
your fingers (1), and pull out the staple case
from the cartridge (2).
Important • The staple case cannot be removed when the
staples are remained in the staple case.
Forcibly removing the staple case may cause
machine malfunction.
5
Insert the front side of the new staple case into
the staple cartridge (1), and then push the rear
side into the cartridge (2).
6
With grasping the orange lever of the staple
cartridge, push the staple cartridge into its
original position until it clicks into place.
7
Close the finisher front door.
Note • If the front door is not closed completely, a message appears and the machine will remain paused.
1
1
2
1
2
