282 Maintenance
5 Pull the standard 550 sheet tray out of the printer about 200 mm. Hold the standard 550 sheet tray with both
hands, and remove it from the printer.
6 Remove the two screws joining the printer and the optional 550 sheet feeder by unscrewing them with a coin or
similar object.
NOTE:
• The screw hole is located in 145 mm recess from the front of the printer.
7 Gently lift the printer off the optional 550 sheet feeder, and place it on a level surface.
When you remove the multiple optional 550 sheet feeders, go to step 8.
When you remove a single optional 550 sheet feeder, go to step 13.
8 Pull the optional 550 sheet tray out of another optional 550 sheet feeder.
To Next Page
