To define a centerline
Do one of the following:
Hold down the left mouse button and draw the centerline in any of the views. (desktop only)
Draw the centerline by dragging your finger on any of the views. (touchscreen only)
Define a centerline by clicking points in any of the views.
You can zoom and scroll through slices while defining a centerline.
To adjust the centerline
Click and drag any of the handles along the centerline.
To rotate the curved MPR view
Click and drag anywhere in the curved MPR view.
To reset curved MPR (desktop only)
Press the D key.
To undo changes to the centerline (desktop only)
Press the Z key.
Pressing the Z key repeatedly will undo successive changes.
Working with thick slabs
Thick slabbing is useful for viewing a thicker portion of the data in a single image.
In some implementations, thick slabbing will be enabled by default as soon as you select the
MIP/MPR view mode.
To enable thick slab
Select Thick Slab from the view menu. The thickness of the slab will be displayed in the
view (by default, this is 10 times the acquisition slice thickness).
To adjust the thickness of the slab
Click the + or - buttons.
