System expansions Installing and removing drives
36 A26361-K554-Z100-2-7619
Mounting a hard disk drive in a 5¼" slot
i
To do this, you require a special mounting frame.
Ê Open the system unit (see "Opening the system unit").
Ê Make the required settings (e. g. master-slave) on the hard disk drives.
Ê Fasten the drive with the four screws in the installation frame.
Ê Install the installation frame with the drive in the desired 5¼" slot (see "Installing an accessible
drive").
Ê Close the slot with the panel. Ensure that the cover engages.
Ê Close the system unit (see "Assembling the system unit").
