5. CONTROL SYSTEM
INDOOR UNIT TYPE AND THE APPLICABLE CONTROL METHOD

Type Model
Indoor units
Compact
Cassette
Slim Duct
Wall mounted
Floor /
Ceiling
Floor
LJ LU LM LF
Central Remote
Controller
UT Y-DMM

M

*1

*1

*1

*1

*1

*1

*1

*1
Wired Remote
Controller
UT Y-RVN

M
  
*2

*3

*4
  
UT Y-RNN

M
  
*2

*3

*4
  
Wireless Remote
Controller
AR-RAH2E
- - - - -
 
-
AR-RAH1E

-

- - - -

AR-REA2E
- - -

- - - -
AR-REB1E
- - - -

- - -
IR Receiver Unit UT Y-LRH

M
-

- - - - - -
Simple Remote
Controller
UTY-RSN

M
  
*2

*3

*4
  

: Accessory,

: Optional, –: Not Applicable.
*1: Central remote controller is connected with Branch box.
*2: Optional Communication kit (UTY-XCBXZ1) is necessary for installation.
*3: Optional Communication kit (UTY-TWBXF) is necessary for installation.
*4: Optional Communication kit (UTY-XCBXZ2) is necessary for installation.
RESTRICTION OF WIRELESS REMOTE CONTROLLER

FUNCTIONS
The following indicates the restrictions of the wireless remote controller when used in
combination with other controllers to one indoor unit.
Model name
Wireless remote
controller functions
Wireless Remote
Controller only
Wireless Remote
Controller
+
Wired / Simple
Remote Controller
Wireless Remote
Controller
+
Central Remote
Controller
Wireless Remote
Controller
+
Wired / Simple
Remote Controller
+
Central Remote
Controller
AR-RAH1E

AR-RAH2E
UT Y-LRH

M
TIMER
   
SLEEP TIMER
   
10°C HEAT
   
AR-REA2E
TIMER
   
SLEEP TIMER
   
10°C HEAT
   
WEEKLY TIMER
   
POWERFUL
   
LOW NOISE
   
AR-REB1E
TIMER
   
SLEEP TIMER
   
10°C HEAT
   
POWERFUL
   
LOW NOISE
   

: This function is available.

: This function is not available.
- (05 - 04) -
CONTROL SYSTEM CONTROL SYSTEM

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
