3. OUTDOOR UNIT & BRANCH BOX
Select the breaker based on MFA of the table above.
Select the wire size based on the larger value of MCA or MFA of the table above.
*1 Wiring Spec : These values are recommended data. Please select the wiring spec in accordance with local rules.
*2 Limited Wiring Length : This wiring length is in case voltage drop less than 2%. When wiring length extend longer,
select the wiring size of larger diameter.
MCA : Min Circuit Amp = Max Operating Current (Full Load)
MFA : Main Fuse (Circuit Breaker) Current
MSC : Max Starting Current
RLA : Rated Load Amp of compressor under the standard condition.
FLA : Full Load Amp of fan motor under the standard condition.
ELECTRIC CHARACTERISTICS8.
OUTDOOR UNIT8-1.
Power Supply Full Load Characteristics iring pecications  Compresser Outdoor Fan Motor
Model name Hz
Voltage
(V)
MCA
(A)
MFA
(A)
MSC
(A)
Power Cable
(mm
2
)
Earth Cable
(mm
2
)
Limited Wiring
Length*2
(m)
RLA
(A)
Output
(kW)
FLA
(A)
AO

G45LBT8 50 230 26.5 32 23.4 6 6 16 21 0.11 0.9
BRANCH BOX8-2.
Power Supply Full Load Characteristics iring pecications 
Model name Hz
Voltage
(V)
MCA
(A)
MFA
(A)
Power Cable
(mm
2
)
Earth Cable
(mm
2
)
Limited Wiring
Length*2
(m)
UTP-PY03A 50 230 3 15 2.5 2.5 14
UTP-PY02A 50 230 3 15 2.5 2.5 14
- (03 - 19) -
OUTDOOR UNITS OUTDOOR UNITS

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
