6. SYSTEM DESIGN
WIRING DESIGN4.
ELECTRICAL WIRING4-1.
PRECAUTION FOR ELECTRICAL WIRING

Regulation on wire diameter and selecting circuit breaker size differ from locality.
Install in accordance with local rules and regulations.
Warning
Do not turn on the power until all installation work is complete.
Before starting work, check that power is not being supplied to the unit.
Connect the connection cable firmly to the terminal board. Imperfect installation may cause a fire.
Always fasten the outside covering of the connection cable with the cord clamp. (If the insulator is 
chafed, electric leakage may occur.)
Make sure to install Earth leakage breaker. Otherwise, it may cause electric shock or a fire.
Always connect the ground wire.
Never install a condenser for improving the power factor. (It will not improve the power factor and 
the condenser will become extremely hot.)
- (06 - 38) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
