6. SYSTEM DESIGN
MOUNTING POSITION1-4.
OUTDOOR UNIT

For the air conditioner to operate satisfactorily, install it as outlined in installation manual.
Outdoor unit mounting position

A position where satisfies the mounting space described in “3-3 Installation space".
A position where the unit can be installed horizontally.
A position with enough space for performing pipe work, service and maintenance.
Outdoor unit mounting limitation

A position that is not exposed to strong or seasonal winds.
A position where the blown air does not accumulate.
A position where there are no obstructions to the air near the inlet and outlet.
A position not exposed to radiation from other heat sources.
A position where the discharge air will not affect animals or plants.
A position where the noise and hot air will not disturb the neighbour.
A position with strong installation fixings, which can sufficiently bear the product weight.
A position that does not transmit noise or vibration.
A position where drain water discharge is not a problem.
A position where snow does not accumulate.
A position not easily affected by electrical noise.
A position out of reach of children.
A position where there is no danger of the generation, influx or accumulation of flammable gas.
A position that does not have a special environment such as large amounts of oil, vapor or 
sulfide gas.
- (06 - 09) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
