6. SYSTEM DESIGN
PRECAUTION

 eect the instaation ocation that eets the oowing reuireent and that is approed b the
customer.
 od and war air shoud reach the entire roo.
Installation height *1
D≦1000 mm
D
floor
*2
*1) Refer to Design & Technical manual for Air velocity distribution and Air temperature distribution during heating.
  the distance ro the ceiing is not adeuate it a cause idew stains on the wa or the ceiing. nsure to 
at least 150 mm away from any surface of the equipment.)
 o not insta the unit in the oowing areas
 he upper part o the icinit o roo entrance. t a cause condensation on the outet port.
 ear a wa surace. t a cause condensation on the wa during cooing.
 rea ed with inera oi or containing a arge aount o spashed oi or stea such as a itchen.
 he pace where it wi be eposed to direct sunight. r ese it a cause a change in coor.
 hen the instaation area is eposed to direct sunight tae easures to boc the ight such as
covering the grille surface with a sheet. Or else, it may cause a change in color.
 se an appropriate rie that is copatibe with the indoor unit.  not used with the correct
combination, it may cause condensation.
 Peror heat insuation and ed setting according the esign  echnica anua o ndoor unit.
Not installing as per the instructions may cause condensation.
- (06 - 145) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
