- 116 -
CASSETTE TYPE
AUXG18-54LRLB
8-2. Sound level check point
NOTE: Detailed shape of the actual outdoor unit might be slightly different from the one illustrated
above.
1 m
MicrophoneMicrophone
Rear
Center
Airflow
Rear viewSide view
1 m
Airflow
MicrophoneMicrophone
Rear
Rear viewSide view
Center
