- 15 -
CASSETTE TYPE AUXG18-54LRLB
4. Dimensions
4-1. Models: AUXG18LRLB and AUXG24LRLB
 Ceiling opening and hanging bolt pitch
 Refrigerant piping and drain piping positions
246 256
40 10
140–145
50–100
950 (Panel frame)
20–45 20–45
50
80
130
130
130
200
840 (Body frame)
796 (Hanging bolt pitch)
768 (Hanging bolt pitch)
860–910 (Ceiling opening)
950 (Panel frame)
840 (Body frame)
860–910 (Ceiling opening)
20–4520–45
Unit: mm
45
293342
140
180
200
Drain pipe
(Connect the attached drain hose)
Unit: mm
