CASSETTE TYPE AUXG18-54LRLB
12. Function settings (Only for AOYG45LBTA and
AOYG54LBTA)
Perform appropriate function setting locally according to the installation environment.
NOTE: Incorrect settings can cause a product malfunction.
!
CAUTION
• Before setting up the switch buttons, discharge the static electricity from your body.
• Never touch the terminals or the patterns on the parts that are mounted on the PCB.
12-1. Local setting switch buttons
 Control PCB and switch buttons location
Control PCB of the outdoor unit is located as shown in the following figure.
Terminal block
Switch buttons
LED lamps
