- 13 -
CASSETTE TYPE
AUXG18-54LRLB
3-2. Models: AUXG30LRLB, AUXG36LRLB, AUXG45LRLB, and
AUXG54LRLB
Type
Cassette
Inverter heat pump
Model name AUXG30LRLB AUXG36LRLB AUXG45LRLB AUXG54LRLB
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 8.5 9.5 12.5 13.3
Btu/h 29,000 32,400 42,700 45,400
Min.—Max.
kW 2.8—10.0 2.8—11.2 4.0—14.0 4.5—14.5
Btu/h 9,500—34,100 9,500—38,200 13,700—47,800 21,200—49,500
Heating
Rated
kW 10.0 10.8 14.0 15.8
Btu/h 34,100 36,900 47,800 53,900
Min.—Max.
kW 2.70—11.20 2.7—12.7 4.2—16.2 4.7—16.5
Btu/h 9,200—38,200 9,200—43,300 14,300—55,300 16,000—56,300
Input power
Cooling
Rated
kW
2.56 2.96 3.85 4.38
Max. 3.88 4.56 4.70 4.94
Heating
Rated 2.77 2.91 3.73 4.58
Max. 3.88 4.56 4.70 4.94
Fan
HIGH
W
52 87 106 129
MED 39526095
LOW 31394555
QUIET 20233034
Current
Cooling
Rated A
11.2 13.0 16.8 19.1
Heating 12.212.716.320.0
Power factor
Cooling
%
99.4 99.0 99.6 99.2
Heating 98.799.699.599.6
EER Cooling
kW/kW
3.32 3.21 3.25 3.04
COP Heating 3.61 3.71 3.75 3.45
Moisture removal L/h (pints/h) 2.5 (4.4) 3.3 (5.8) 4.5 (7.9) 5.0 (8.8)
Maximum operating current *1
Cooling
A
17.0 20.0 20.5 21.5
Heating 17.0 20.0 20.5 21.5
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,600 1,900 2,000 2,100
MED 1,400 1,590 1,650 1,780
LOW 1,270 1,420 1,460 1,600
QUIET 1,150 1,180 1,300 1,320
Heating
HIGH 1,600 1,900 2,000 2,100
MED 1,400 1,590 1,650 1,780
LOW 1,270 1,420 1,460 1,600
QUIET 1,150 1,180 1,300 1,320
Type × Q'ty Turbo fan × 1
Motor output W 81
Sound pressure level *2
Cooling
HIGH
dB (A)
40 44 46 47
MED 38414243
LOW 36383940
QUIET 33343536
Heating
HIGH 40 44 46 47
MED 38414243
LOW 36383940
QUIET 33343536
Sound power level
Cooling
HIGH dB (A)
54 58 60 61
Heating 54586061
Heat exchanger type
Dimensions (H × W × D)
mm
252 × 2,124 × 13.3
252 × 2,062 × 13.3
252 × 2,124 × 13.3
252 × 2,062 × 13.3
252 × 1,999 × 13.3
Fin pitch 1.2 1.3
Rows × Stages 2 × 12 3 × 12
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
mm
288 × 840 × 840
Gross 350 × 960 × 950
Weight
Net
kg
26 29
Gross 32 34
Connection
pipe
Size
Liquid
mm (in)
Ø 9.52 (Ø 3/8)
Gas Ø 15.88 (Ø 5/8)
Method Brazing
Drain hose
Material PVC(VP25)
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Cassette grille
Material PS
Color
White
Approximate color of MUNSELL N 9.25/
Dimensions
(H × W × D)
Net
mm
53 × 950 × 950
Gross 110 × 1,000 × 1,010
Weight
Net
kg
6.0
Gross 10.5
