- 19 -
CASSETTE TYPE
AUXG18-54LRLB
4-3. Installation space requirement
Provide sufficient installation space for product safety.
For 4-direction setting (AUXG18LRLB and AUXG24LRLB):
*: For the details of position adjustment by ceiling mode, refer to “Contents of function setting” on
page 69.
For 4-direction setting (AUXG30LRLB, AUXG36LRLB, AUXG45LRLB, and AUXG54LRLB):
*: For the details of position adjustment by ceiling mode, refer to “Contents of function setting” on
page 69.
1,500
or more
1,000 or more
1,800 or more
Obstruction
3,000 or more
Strong and durable ceiling
Floor
Ceiling height
Ceiling mode* “Low” : 2.7 m
Ceiling mode “Standard” : 3.0 m
Ceiling mode “High” : 3.5 m
256 or more
Unit: mm
1,500
or more
1,000 or more
1,800 or more
Obstruction
3,000 or more
Strong and durable ceiling
Floor
Ceiling height
Ceiling mode* “Low” : 2.7 m
Ceiling mode “Standard” : 3.2 m
Ceiling mode “High” : 4.2 m
298 or more
Unit: mm
