- 20 -
CASSETTE TYPE
AUXG18-54LRLB
For 3-direction setting:
NOTES:
• To set “3-direction”, optional Air outlet shutter plate (UTR-YDZK) must be installed, and the
“outlet-direction” need to be switched to “3-way” by remote controller.
• The ceiling height cannot be set in the 3-way outlet mode. Therefore, ceiling height setting change
by function setting 20 is prohibited. For details, refer to “Contents of function setting” on page 69.
Human sensor(Option)
Example of sensitivity range:
When the installation height gets higher, the temperature sensitivity decreases.
Do not place large objects near the human sensor. Also keep heating units outside the sensor’s
detection area.
Equal sensitivity range of temperature
Ceiling height 3,200 mm
Detecting position 800 mm from floor surface
