5) Static pressure (for Mini duct type and Slim duct type)
Select the appropriate static pressure according to the installation conditions.
For mini duct type:
Function number Setting value Setting description Factory setting
26
00 0 Pa
01 10 Pa
02 20 Pa
03 30 Pa
04 40 Pa
05 50 Pa
31
Standard
(10 Pa: 07; 09; 12 models, 15 Pa: 14; 18
models)
♦
NOTES:
• Range of static pressure is different by model.
Model Range of static pressure
07, 09, 12 models 0 to 30 Pa
14, 18 models 0 to 50 Pa
• Setting number in 07, 09, 12 models is “04 to 30”: Operation is same as that “03”.
• Setting number in 14, 18 models is “06 to 30”: Operation is same as that “05”.
• Setting number value cannot be set to 32 or more.
For slim duct type:
Function number Setting value Setting description Factory setting
26
00 0 Pa
01 10 Pa
02 20 Pa
03 30 Pa
04 40 Pa
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
31 Standard (25 Pa) ♦
6) Horizontal louver direction switching for dew condensation prevention (for KE model in
Wall-mounted type only)
Automatically switches the position of the horizontal louver if the airflow direction is set at lower than
the dew condensation limit position in cooling or drying operation.
Select suitable adjustment position according to the customer’s preference.
Function number Setting value Setting description Factory setting
28
00 Adjust to dew condensation limit position ♦
01 Adjust to cooling standard position
- 305 -
15-5. Function details 15. Function settings
3-UNIT
MULTI-SPLIT TYPE
3-UNIT
MULTI-SPLIT TYPE
