Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
21
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
19
-10.0
5.3 0.84 6.0 0.86 6.4 0.86 6.8 0.87 7.3 0.88 7.5 0.89
0.0 5.3 1.00 6.0 1.02 6.4 1.03 6.8 1.04 7.3 1.05 7.5 1.06
5.0 5.3 1.07 6.0 1.09 6.4 1.10 6.8 1.11 7.3 1.12 7.5 1.13
10.0 5.3 1.16 6.0 1.18 6.4 1.19 6.8 1.20 7.3 1.22 7.5 1.22
15.0 5.3 1.07 6.0 1.09 6.4 1.10 6.8 1.11 7.3 1.12 7.5 1.13
20.0 5.3 1.00 6.0 1.02 6.4 1.03 6.8 1.04 7.3 1.05 7.5 1.06
25.0 5.3 1.23 6.0 1.25 6.4 1.26 6.8 1.28 7.3 1.29 7.5 1.30
30.0 5.3 1.41 6.0 1.44 6.4 1.45 6.8 1.47 7.3 1.48 7.5 1.49
35.0 5.3 1.76 6.0 1.79 6.4 1.81 6.8 1.83 7.3 1.85 7.5 1.86
40.0 4.7 1.68 5.3 1.71 5.6 1.72 6.0 1.74 6.4 1.76 6.6 1.77
46.0 4.7 1.59 5.3 1.62 5.6 1.63 6.0 1.65 6.4 1.67 6.6 1.68
18
-10.0
5.0 0.79 5.7 0.80 6.0 0.81 6.4 0.82 6.8 0.83 7.1 0.83
0.0 5.0 0.94 5.7 0.96 6.0 0.97 6.4 0.98 6.8 0.99 7.1 0.99
5.0 5.0 1.00 5.7 1.02 6.0 1.03 6.4 1.04 6.8 1.05 7.1 1.06
10.0 5.0 1.09 5.7 1.11 6.0 1.12 6.4 1.13 6.8 1.14 7.1 1.15
15.0 5.0 1.00 5.7 1.02 6.0 1.03 6.4 1.04 6.8 1.05 7.1 1.06
20.0 5.0 0.94 5.7 0.96 6.0 0.97 6.4 0.98 6.8 0.99 7.1 1.00
25.0 5.0 1.16 5.7 1.18 6.0 1.19 6.4 1.20 6.8 1.21 7.1 1.22
30.0 5.0 1.33 5.7 1.35 6.0 1.36 6.4 1.38 6.8 1.39 7.1 1.40
35.0 5.0 1.66 5.7 1.68 6.0 1.70 6.4 1.72 6.8 1.74 7.1 1.75
40.0 4.4 1.58 5.0 1.60 5.3 1.62 5.7 1.64 6.1 1.65 6.2 1.66
46.0 4.4 1.50 5.0 1.52 5.3 1.54 5.7 1.55 6.1 1.57 6.2 1.58
16
-10.0
4.5 0.70 5.1 0.71 5.3 0.72 5.7 0.73 6.1 0.73 6.3 0.74
0.0 4.5 0.83 5.1 0.85 5.3 0.86 5.7 0.87 6.1 0.88 6.3 0.88
5.0 4.5 0.89 5.1 0.91 5.3 0.91 5.7 0.92 6.1 0.93 6.3 0.94
10.0 4.5 0.97 5.1 0.98 5.3 0.99 5.7 1.00 6.1 1.01 6.3 1.02
15.0 4.5 0.89 5.1 0.91 5.3 0.91 5.7 0.92 6.1 0.93 6.3 0.94
20.0 4.5 0.84 5.1 0.85 5.3 0.86 5.7 0.87 6.1 0.88 6.3 0.88
25.0 4.5 1.02 5.1 1.04 5.3 1.05 5.7 1.06 6.1 1.07 6.3 1.08
30.0 4.5 1.18 5.1 1.20 5.3 1.21 5.7 1.22 6.1 1.24 6.3 1.24
35.0 4.5 1.47 5.1 1.49 5.3 1.51 5.7 1.52 6.1 1.54 6.3 1.55
40.0 4.0 1.40 4.5 1.42 4.7 1.43 5.0 1.45 5.4 1.47 5.6 1.47
46.0 4.0 1.33 4.5 1.35 4.7 1.36 5.0 1.38 5.4 1.39 5.6 1.40
14
-10.0
3.9 0.63 4.4 0.64 4.7 0.65 5.0 0.65 5.3 0.66 5.5 0.66
0.0 3.9 0.75 4.4 0.76 4.7 0.77 5.0 0.78 5.3 0.79 5.5 0.79
5.0 3.9 0.80 4.4 0.81 4.7 0.82 5.0 0.83 5.3 0.84 5.5 0.84
10.0 3.9 0.87 4.4 0.88 4.7 0.89 5.0 0.90 5.3 0.91 5.5 0.92
15.0 3.9 0.80 4.4 0.82 4.7 0.82 5.0 0.83 5.3 0.84 5.5 0.85
20.0 3.9 0.75 4.4 0.77 4.7 0.77 5.0 0.78 5.3 0.79 5.5 0.79
25.0 3.9 0.92 4.4 0.94 4.7 0.95 5.0 0.96 5.3 0.97 5.5 0.97
30.0 3.9 1.06 4.4 1.08 4.7 1.09 5.0 1.10 5.3 1.11 5.5 1.12
35.0 3.9 1.32 4.4 1.34 4.7 1.35 5.0 1.37 5.3 1.39 5.5 1.39
40.0 3.5 1.26 3.9 1.28 4.1 1.29 4.4 1.30 4.7 1.32 4.9 1.33
46.0 3.5 1.19 3.9 1.21 4.1 1.22 4.4 1.24 4.7 1.25 4.9 1.26
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected indoor unit is from 14,000 Btu/h up to 30,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 355 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT
AOYG18-24KBTA3
OUTDOOR UNIT
AOYG18-24KBTA3
