Fujitsu AOYG24KBTA3 Design & Technical Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
-5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
0.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
15.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
20.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
25.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
30.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
35.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
40.0 1.74 1.05 1.97 1.19 2.08 1.37 2.23 1.54 2.38 1.69 2.45 1.94
46.0 1.51 0.78 1.71 0.89 1.80 1.03 1.93 1.16 2.06 1.26 2.12 1.45
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
-5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 2.23 1.32 2.52 1.51 2.66 1.74 2.85 1.95 3.04 2.13 3.14 2.45
46.0 1.93 0.99 2.18 1.13 2.30 1.30 2.46 1.46 2.63 1.60 2.72 1.83
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
-5.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
0.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
5.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
10.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
15.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
20.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
25.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
30.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
35.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
40.0 3.00 1.76 3.39 2.00 3.57 2.30 3.83 2.59 4.09 2.83 4.22 3.24
46.0 2.60 1.31 2.93 1.50 3.09 1.72 3.31 1.94 3.54 2.12 3.65 2.43
Model: AUXG14KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
-5.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
0.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
5.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
10.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
15.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
20.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
25.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
30.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
35.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
40.0 3.26 1.81 3.68 2.06 3.88 2.37 4.16 2.66 4.44 2.91 4.58 3.34
46.0 2.82 1.35 3.19 1.54 3.36 1.77 3.60 1.99 3.84 2.18 3.96 2.50
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 356 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
