Fujitsu AOYG24KBTA3 Design & Technical Manual


Mini duct type
Model: ARXG07KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
-5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.74 1.07 1.97 1.22 2.08 1.41 2.23 1.58 2.38 1.73 2.45 1.99
46.0 1.51 0.80 1.71 0.92 1.80 1.06 1.93 1.19 2.06 1.30 2.12 1.49
Model: ARXG09KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
-5.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
0.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
5.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
10.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
15.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
20.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
25.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
30.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
35.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
40.0 2.23 1.27 2.52 1.45 2.66 1.67 2.85 1.88 3.04 2.05 3.14 2.35
46.0 1.93 0.95 2.18 1.09 2.30 1.25 2.46 1.40 2.63 1.54 2.72 1.76
Model: ARXG12KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
0.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
15.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
20.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
25.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
30.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
35.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
40.0 3.00 1.71 3.39 1.95 3.57 2.24 3.83 2.52 4.09 2.76 4.22 3.16
46.0 2.60 1.28 2.93 1.46 3.09 1.68 3.31 1.89 3.54 2.06 3.65 2.36
Model: ARXG14KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
-5.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
0.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
5.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
10.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
15.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
20.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
25.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
30.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
35.0 3.66 2.25 4.14 2.56 4.36 2.95 4.67 3.32 4.99 3.63 5.15 4.15
40.0 3.26 1.78 3.68 2.03 3.88 2.34 4.16 2.63 4.44 2.87 4.58 3.29
46.0 2.82 1.33 3.19 1.52 3.36 1.75 3.60 1.97 3.84 2.15 3.96 2.46
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
- 357 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
