Fujitsu AOYG24KBTA3 Design & Technical Manual


Slim duct type
Model: ARXG07KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
-5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.74 1.07 1.97 1.22 2.08 1.41 2.23 1.58 2.38 1.73 2.45 1.99
46.0 1.51 0.80 1.71 0.92 1.80 1.06 1.93 1.19 2.06 1.30 2.12 1.49
Model: ARXG09KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
-5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 2.23 1.32 2.52 1.51 2.66 1.74 2.85 1.95 3.04 2.13 3.14 2.45
46.0 1.93 0.99 2.18 1.13 2.30 1.30 2.46 1.46 2.63 1.60 2.72 1.83
Model: ARXG12KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
-5.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
0.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
5.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
10.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
15.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
20.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
25.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
30.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
35.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
40.0 3.00 1.80 3.39 2.05 3.57 2.36 3.83 2.66 4.09 2.91 4.22 3.33
46.0 2.60 1.35 2.93 1.54 3.09 1.77 3.31 1.99 3.54 2.17 3.65 2.49
Model: ARXG14KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
-5.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
0.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
5.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
10.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
15.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
20.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
25.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
30.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
35.0 3.66 2.34 4.14 2.67 4.36 3.08 4.67 3.46 4.99 3.78 5.15 4.33
40.0 3.26 1.86 3.68 2.12 3.88 2.44 4.16 2.74 4.44 2.99 4.58 3.43
46.0 2.82 1.39 3.19 1.58 3.36 1.82 3.60 2.05 3.84 2.24 3.96 2.57
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 358 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
