Model name AUYG14LVLB AUYG18LVLB
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kW class 4.0 5.0
Input power W 28 39
Running current A 0.22 0.30
Fan
Airflow rate
Cooling
HIGH
m
3
/h
680 750
MED 580 610
LOW 490 520
QUIET 410 410
Heating
HIGH 700 800
MED 620 710
LOW 550 600
QUIET 430 450
Type × Q'ty Turbo fan × 1
Motor output W 54
Sound pressure level *
Cooling
HIGH
dB (A)
40 42
MED 35 37
LOW 32 33
QUIET 29 29
Heating
HIGH 40 44
MED 37 40
LOW 34 37
QUIET 29 30
Sound power level
Cooling
dB (A)
52 54
Heating 52 56
Heat exchanger type
Dimensions (H × W × D) mm 210 × 1,310 × 13.3 + 210 × 1,250 × 13.3
Fin pitch mm 1.2
Rows × Stages 2 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
mm
245 × 570 × 570
Gross 265 × 730 × 625
Weight
Net
kg
15
Gross 18
Connection
pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Drain hose
Material Hard PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Cassette grille
Model name UTG-UFYD-W
Material PS
Color
White
(Approximate color of Munsell N 9.25/)
Dimensions
(H × W × D)
Net
mm
49 × 700 × 700
Gross 120 × 765 × 755
Weight
Net
kg
2.6
Gross 4.5
Remote controller type Wireless (Wired [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
